LIS-20 Series

LCD testing workbench

You can build your own LIS-20 series by the combination of any component units.
An ideal testing device can be realized instantly.

LIS-20 SERIES

Any following component units can be chosen to meet test requirements.

[Interface Unit]

  • MPU I/F
  • Digital
  • MDDI
  • Analog - single phase
  • Analog - 6 phases
  • Analog - 12 phases

[Signal Generator]

  • Test patterns - simple patterns, complicated patterns (bitmap), moving pictures
    *Patterns for screen tests can be created with PC software for drawing.
    *MECC accepts orders to create special test patterns optionally.
  • External devices such as a barcode reader or a camera for positioning can be connected.

[LCD power supply]

  • Analog panels 3" size or smaller
  • Analog panels 3" size to 8" size
  • Digital panels 3" size or smaller
  • Digital panels 3" size to 8" size
  • LCD panel strips/bars

[Backlight power supply]

  • Panels 3" size to 8" size
  • Panels 3" size to 8" size
  • LCD panel strips/bars

[Backlight unit]

  • Panels 3" size to 8" size
  • Panels 3" size to 8" size
  • LCD panel strips/bars

[LCD panel holder unit]

  • Panels 3" size to 8" size
  • Panels 3" size to 8" size
  • LCD panel strips/bars

[Bench]

  • For standing operation; Table: 1000W x 650D x1000H (mm)
  • For sitting operation; Table: 1600W x 650D x750H (mm)

*Combination sample (image) for standing operation
STANDING TYPE
*Combination sample (image) for sitting operation
SITTING TYPE
